Webgate I-Rec B104

Technical Specification

Features:

Make: Webgate
Model code: i-Rec B104
Series: I-Rec Series
Channels: 4
Recording Mode: Real Time

Additional info:

IP recording solution (not a video server but similar) used either locally or remotely to cameras and must be used in conjunction with a PC for storage and operability (hence variable storage capacity). RS 232 and RS 485/RS422 Port Support for PTZ Control. Dynamic IP (DHCP, Floating IP) support (when you use xDSL and Cable Modem).

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Webgate
Manufacturer	Webgate Inc.
Category	Video Surveillance>Digital video recorders (DVRs)
Model code	i-Rec B104
Series	I-Rec Series
Channels	4
Recording Mode	Real Time
Monitor Outputs	4
Inbuilt Multiplexer	Yes
Multiplexer Type	Duplex
Image per second (IPS)	max 25 PAL / 1 cam
Compression Type	Wavelet
Resolution	720 x 486
Signal Mode	PAL, NTSC
Recording System	HDD
Mount type	4 in, 4 out
Network Type	TCP/IP, ARP, RARP, ICMP
Additional info	IP recording solution (not a video server but similar) used either locally or remotely to cameras and must be used in conjunction with a PC for storage and operability (hence variable storage capacity). RS 232 and RS 485/RS422 Port Support for PTZ Control. Dynamic IP (DHCP, Floating IP) support (when you use xDSL and Cable Modem).
Download PDF version Download PDF version
