Siemens CMTC1723 17-inch LCD TFT Colour Monitor

Technical Specification

Please note: this is a discontinued product.

Go to Replacement product

Features:

Make: Vanderbilt
Model code: CMTC1723
Monitor Type: TFT LCD
Effective Screen Size Inches: 17
Color Type: Color

Additional info:

The high-resolution TFT monitor has been specifically designed for CCTV applications and is ideally suited for use with digital video recorders (DVR) and PC applications. The monitor has two BNC video inputs with loop-through outputs, one loop-through SVHS and one DVI input which enables the monitor to be used with DVRs and for PCbased applications.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Vanderbilt
Manufacturer	Vanderbilt Industries
Category	Video Surveillance>Security Monitors
Model code	CMTC1723
Monitor Type	TFT LCD
Effective Screen Size Inches	17
Color Type	Color
Resolution	1280 x 1024
Signal Mode	PAL/NTSC
Built-in Speaker	Yes
Monitor Mount Type	Wall
Dimensions mm	382 x 392 x 196
Weight kg	6.2
Environmental Specifications	Operating Temperature ^oC: 0 ~ 40 Operating Humidity %: 0 ~ 80
Electrical Specifications	Power Consumption: 50 W Voltage: 100 ~ 240 V AC
Scanning Frequency Hz	h: 31 ~ 64 KHz, v: 56 ~ 75 Hz
Video Input	2 x BNC, 1 x Mini DIN 4-pin (S-Video, Y/C)
Additional info	The high-resolution TFT monitor has been specifically designed for CCTV applications and is ideally suited for use with digital video recorders (DVR) and PC applications. The monitor has two BNC video inputs with loop-through outputs, one loop-through SVHS and one DVI input which enables the monitor to be used with DVRs and for PCbased applications.
