Honeywell Security HS10PIT CCTV switcher

Technical Specification

Features:

Make: Honeywell Security
Model code: HS10PIT
Dimensions mm: 442.5 x 47.75 x 182.25
Weight g: 2,300
Voltage: 100 ~ 240 V AC

Additional info:

MegaPITTM is a system accessory for small-to-large video matrix installations, providing two different primary purposes. As a port expander, it connects a single serial output from a MAXPRO-Net server and provides eight serial outputs for connection to field devices. As a hot changeover device, it allows for two redundant MAXPRO-Net servers to be used so that in the unlikely event of a server malfunction MegaPIT will automatically switch system control to the operational server to ensure system integrity.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Honeywell Security
Manufacturer	Honeywell
Category	Video Surveillance>Switchers & Switches
Model code	HS10PIT
Physical Specifications	Dimensions mm: 442.5 x 47.75 x 182.25 Weight g: 2,300
Electrical Specifications	Voltage: 100 ~ 240 V AC Power Consumption: 2 A @ 12 VDC
Environmental Specifications	Operating Temperature ^oC: -10 ~ +50 Operating Humidity %: 0 ~ 95
Accessories	Port expander and automatic changeover unit
Additional info	MegaPITTM is a system accessory for small-to-large video matrix installations, providing two different primary purposes. As a port expander, it connects a single serial output from a MAXPRO-Net server and provides eight serial outputs for connection to field devices. As a hot changeover device, it allows for two redundant MAXPRO-Net servers to be used so that in the unlikely event of a server malfunction MegaPIT will automatically switch system control to the operational server to ensure system integrity.
