Hanwha Techwin America Techwin SVR-940 4-channel High-quality Digital Video Recorder

Technical Specification

Please note: this is a discontinued product.

Go to Replacement product

Features:

Make: Hanwha Vision
Previously known as: Samsung
Model code: SVR-450
Channels: 4
Recording Mode: Real Time / Timelapse / Event

Additional info:

The SVR-450 is the best DVR solutions for implementation of smalland medium scale security systems. The solutions allow you to upgrade your CCTV system from analog to digital at an affordable price by integrating various DVR features. These features include MPEG-4 high quality compression, built-in support for up to 250GB as a standard HDD, real-time video recording for each channel at 30fps(SVR-450/440), a simple graphic interface menu, simple real-time monitoring of a remote site via a network, and a built-in CD-RW drive.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Hanwha Vision
Manufacturer	Hanwha Vision America
Previously known as	Samsung
Category	Video Surveillance>Digital video recorders (DVRs)
Model code	SVR-450
Channels	4
Recording Mode	Real Time / Timelapse / Event
Monitor Outputs	1
Inbuilt Multiplexer	Yes
Alarm I/O	4 in, 1 out
Multiplexer Type	Triplex
Storage Capacity GB	250
Image per second (IPS)	120 over all cameras
Compression Type	MPEG
Resolution	704 x 480 (N), 704 x 576 (P)
Signal Mode	PAL, NTSC
External Storage	USB, CD-RW
Recording System	HDD
Audio Recording and Properties	4 in, 1 out
Mount type	4 in, 1 out
Network Type	RJ-45 (10/100 Base-T)
Physical Specifications	Dimensions mm: 430 x 88.8 x 362 Weight kg: 8.9
Electrical Specifications	Voltage: 100 ~ 240 V AC Power Consumption: 60 W
Environmental Specifications	Operating Temp ^oC: 5 ~ 40 Operating Humidity %: 0 ~ 60
Additional info	The SVR-450 is the best DVR solutions for implementation of smalland medium scale security systems. The solutions allow you to upgrade your CCTV system from analog to digital at an affordable price by integrating various DVR features. These features include MPEG-4 high quality compression, built-in support for up to 250GB as a standard HDD, real-time video recording for each channel at 30fps(SVR-450/440), a simple graphic interface menu, simple real-time monitoring of a remote site via a network, and a built-in CD-RW drive.
