IndigoVision 562429 2MP Fixed IP Dome Camera

Technical Specification

Features:

Make: IndigoVision
Model code: 562429
Chip Inch Size: 1/3
Color Type: True Day / Night
Resolution TVL: 2 MP

Additional info:

IndigoVision 562429 2MP fixed IP dome camera with telephoto lens features SMART.core technology that gives H.264 compression and ACF+, reducing storage costs by up to 95%. The camera also features WDR, motion detection as well as it is ONVIF supported.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	IndigoVision
Manufacturer	IndigoVision Inc.
Category	Video Surveillance>IP Dome cameras
Model code	562429
Chip Inch Size	1/3
Color Type	True Day / Night
Resolution TVL	2 MP
HD	Yes
Megapixel	Yes
Dome Type	Static
Sensitivity lux	0.005
Digital (DSP)	Yes
Mount Type	In-Ceiling
Electrical Specifications	Voltage: 24 V AC Power Consumption: 9.6 W
Focal length	10 ~ 23 mm
Compression	H.264
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/1 ~ 1/50,000 sec
S/ N (Signal/ Noise) Ratio dB	> 39
Signal Mode	PAL
Zoom Ratio	x2.3
Network Properties	Interface: 10/100 Base-T Ethernet Network Protocols: TCP, UDP, RTP, ICMP, IGMP, SNMP, DHCP,NTP, DNS, HTTP, HTTPS, SSH Image Frame Rate: 25 fps
Physical Specifications	Dimensions mm: 225 x 152 x 72 Weight g: 1,100
Environmental Specifications	Operating Temp ^oC: 0 ~ 50 C (32 ~ 122 F)
Additional info	IndigoVision 562429 2MP fixed IP dome camera with telephoto lens features SMART.core technology that gives H.264 compression and ACF+, reducing storage costs by up to 95%. The camera also features WDR, motion detection as well as it is ONVIF supported.
